Transfer Automation

FlexMotion L

Our transfer automation FlexMotion is suitable for all applications in sheet metal forming. With its various sizes, our transfer automation can be used for all press fabricates and all press types (e. g. eccentric presses, link drive presses, hydraulic presses and servo presses).

Technical data

Table length min. 4,000 mm - max. 5,250 mm
Feeding motion min. 0 mm - max. 1,200 mm
Closing motion min. 0 mm - max. 220 mm
Lifting motion min. -30 mm - max. 220 mm
Dimention transfer bar length 150 mm x height 150 mm
Transport weight 150 kg

Closing-Lifting Unit

Specification
  • Mounted on the inlet and outlet side of the press columns
  • Asymetric motion sequences are possible through separate drives
  • Vibration-optimized, mechanical
Options
  • Closing motion adaptable to press window

Transfer Bars

Specification
  • 1 set transfer exchange bars
  • Manuel transfer bars coupling
Options
  • 2 sets transfer exchange bars
  • Automatic transfer bars couplings

Technology Packages

Specification
  • Transport and part monitoring control one-sided
  • Static electronic overload protection
Options
  • Transport and part monitoring control two-sided
  • Special transfer motions
  • Adaptive electronic overload protection
  • Electronic vibration compensation

Control & Visualization

Specification
  • PLC-System Siemens S7
  • Drive unit Sinamics
  • Safety via Safety Integrated
  • Teleservice
  • Control panel TP 1500
  • Visualization with WinCC-Comfort (TIA-Portal)
  • Synoptic automatic operation and tool changes
